| CAPACITY | 2400VA/1600W |
| INPUT | |
| Voltage | 220¬240VAC |
| Selectable Voltage Range | 90¬280VAC |
| Frequency Range | 50Hz/60Hz(Auto Sensing) |
| OUTPUT | |
| AC Voltage Regulation (Batt. Mode) | 220¬240VAC+-10% |
| Overload Capability | Load>110%+-15%, alarm 5 mins and then inverter fault
If decreasing the load until lower than 110%, the overload alarm can release Load>130%+-15%, inverter fault immediately |
| Efficiency(Peak) | 85% |
| Transfer Time | 20ms |
| Waveform | Simulated Sine Wave |
| BATTERY & AC CHARGER | |
| Battery Voltage | 24VDC |
| Floating Charge Voltage | 27.4VDC +-1VDC |
| Overcharge Protection | 30VDC +-0.5VDC |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Maximum PV Array Open Circuit Voltage | 100VDC |
| Maximum PV Array Power | 1200W |
| MPPT Range@ Operating Voltage | 30¬80VDC |
| Maximum Solar Charge Current | 50A |
| Maximum AC Charge Current | 10A/20A |
| Maximum Charge Current | 50A |
| PHYSICAL | |
| Dimension D*W*H(mm) | 272*212*127 |
| Net Weight(kgs) | 4.8 |
| OPERATING ENVIRONMENT | |
| Humidity | 0% to 90% Relative Humidity |
| Operating Temperature | 0¬55C |
| Storage Temperature | -15¬55C |
