GoodWe ES 6kw Hybrid Solar Inverter (Single Phase)
₨ 235,000
Key Features
-
Hybrid design: integrates solar, battery, and grid power
-
Supports both Lithium-Ion & Lead Acid batteries (48V)
-
Max PV input power: 9000W
-
Dual MPPTs for flexible solar array configurations
-
High efficiency: 97.6%
-
LCD Display + remote monitoring via SEMS Portal (App/Web)
-
Silent fanless design with natural convection cooling
-
IP65 protection (dust & water resistant, indoor/outdoor use)
⚡ Important Notice for Customers⚡
All inverter orders will be processed only after receiving an advance payment through bank transfer.
Your order has been placed on Cash on Delivery (COD).
To confirm and process your order, please contact us on WhatsApp at 03321567282 to get the payment details for Electrical Wall Solar Solutions.Once your payment is confirmed, your order will be dispatched through TCS, Asia Cargo, Daewoo, or another preferred delivery service.
🛡️ 5 Years Replacement Warranty
Enjoy complete peace of mind with our comprehensive 5-year replacement warranty.
🚚 Estimated Delivery Time
Orders are typically delivered within 48 to 72 hours after confirmation.
💳 Advance Payment Required
Full payment in advance is required to confirm your order.
🔋 Batteries, Inverters & Structures
A 100% advance payment is mandatory for processing orders of batteries, solar inverters, and mounting structures.
📦 Heavy Weight Shipments
Heavy and oversized parcels will be dispatched through a reliable Cargo Service for safe delivery.
GoodWe ES Uniq GW6000-ES-C10 6kW Hybrid Solar Inverter (Single Phase)
Smart Energy Storage Solution for Modern Homes
The GoodWe ES Uniq GW6000-ES-C10 6kW Hybrid Solar Inverter is an advanced single-phase hybrid inverter designed for residential and small commercial solar applications. Combining solar generation, battery storage, and grid connectivity into one intelligent system, it delivers reliable power, enhanced energy independence, and maximum efficiency.
With support for up to 12kW PV input power, 48V battery systems, and dual output functionality, this inverter ensures optimal energy utilization while providing uninterrupted power for critical loads during grid outages.
Key Features
✅ 6kW Hybrid Solar Inverter (Single Phase)
✅ Dual Output for Smart Load Management
✅ Supports up to 12kW Solar PV Input
✅ Compatible with 48V Battery Systems
✅ 140A Max Charging & Discharging Current
✅ Maximum Efficiency up to 97.6%
✅ IP66 Rated – Suitable for Indoor & Outdoor Installation
✅ LCD Display with Mobile App Monitoring
✅ Wi-Fi, LAN, Bluetooth & RS485 Communication
✅ Lightweight & Compact Wall-Mounted Design
✅ Advanced Safety and Protection Functions
Technical Specifications
| Specification | Details |
|---|---|
| Model | GW6000-ES-C10 |
| Rated Output Power | 6.0 kW |
| Maximum AC Output Power | 6.6 kW |
| Maximum PV Input Power | 12 kW |
| Battery Voltage | 48V |
| Battery Voltage Range | 40V – 60V |
| Maximum Charging Current | 140A |
| Maximum Discharging Current | 140A |
| Maximum AC Output Current | 30A |
| Weight | 15.5 kg |
| Dimensions (W×H×D) | 560 × 415 × 204 mm |
Efficiency Performance
| Parameter | Value |
|---|---|
| Maximum Conversion Efficiency | 97.6% |
| European Efficiency | 96.2% |
| Battery-to-AC Efficiency | 95.5% |
| MPPT Tracking Efficiency | 99.9% |
Advanced Protection Features
✔ PV String Current Monitoring
✔ PV Insulation Resistance Detection
✔ Residual Current Monitoring
✔ PV Reverse Polarity Protection
✔ Anti-Islanding Protection
✔ AC Overcurrent Protection
✔ AC Short Circuit Protection
✔ AC Overvoltage Protection
✔ Integrated DC Switch
✔ Type III DC Surge Protection
✔ Type III AC Surge Protection
✔ Remote Shutdown Capability
✔ Optional AFCI Protection
✔ Optional Rapid Shutdown Function
General Information
| Feature | Details |
|---|---|
| Operating Temperature | -35°C to +60°C |
| Relative Humidity | 0% – 95% |
| Maximum Altitude | 3000 m |
| Cooling System | Natural Convection |
| User Interface | LCD Display + Mobile App |
| BMS Communication | CAN |
| Connectivity | Wi-Fi, LAN, Bluetooth, RS485 |
| Communication Protocols | Modbus-RTU, Modbus-TCP |
| Topology | Non-Isolated |
| Protection Rating | IP66 |
Why Choose GoodWe ES Uniq GW6000-ES-C10?
The GoodWe ES Uniq 6kW Hybrid Inverter is engineered to deliver exceptional performance, intelligent energy management, and long-term reliability. Its high conversion efficiency, powerful battery integration, dual-output capability, and comprehensive protection features make it an ideal choice for homeowners and businesses seeking greater energy independence and lower electricity costs.
